Azure SQL Managed Instance Audit Configuration Guide

Overview

This guide provides comprehensive instructions for configuring audit monitoring for Azure SQL Managed Instance using Netwrix Auditor. The setup involves creating Microsoft Entra ID application registration, configuring Azure Storage for audit logs, setting up database-level auditing, and installing the Netwrix add-on.

Download link:
https://netwrix.com/go/auditor_addon_azure_sql_mi

Prerequisites

Before starting the configuration, ensure you have:

  • Azure Subscription with appropriate permissions
  • Azure SQL Managed Instance deployed and accessible
  • Netwrix Auditor Server installed and running
  • Administrative privileges in Azure portal and SQL Managed Instance
  • Network connectivity between Azure SQL MI and storage account

Architecture Overview

[Azure SQL MI] --> [Audit Logs] --> [Azure Blob Storage] --> [Netwrix Add-on] --> [Netwrix Auditor]

The solution uses:

  • Microsoft Entra ID for authentication
  • Azure Blob Storage for audit log storage
  • Managed Identity for secure access
  • Server and Database level auditing for comprehensive coverage

Step 1: Configure Microsoft Entra ID Application

To integrate with Microsoft Entra ID, you need to create a separate application registration in the Azure portal.

1.1 Register a New Application

  1. Navigate to the Azure Portal
  2. Go to Microsoft Entra ID (formerly Azure Active Directory)
  3. Select App registrations from the left-hand menu
  4. Click + New registration
  5. Configure the application:
    • Name: Choose a descriptive name (e.g., NetwrixSQLMIIntegration)
    • Supported account types: Accounts in this organizational directory only
    • Redirect URI: Leave blank for this scenario
  6. Click Register

1.2 Create a Client Secret

  1. After registration, navigate to Certificates & secrets
  2. Under Client secrets, click + New client secret
  3. Configure the secret:
    • Description: “Netwrix Integration Secret”
    • Expires: Choose appropriate expiration period (recommended: 12-24 months)
  4. Click Add
  5. Important: Copy the secret value - you cannot retrieve it later

1.3 Configure API Permissions (Optional)

If your setup requires specific Azure resource access:

  1. Go to API permissions
  2. Click + Add a permission
  3. Select appropriate Microsoft APIs based on your requirements
  4. Grant admin consent if needed

1.4 Collect Required Information

Record the following values for later configuration:

  • Application (client) ID
  • Directory (tenant) ID
  • Client secret value
  • Application name

Step 2: Configure Azure Storage Account for Log Storage

Azure SQL Managed Instance requires an Azure Storage Account with Blob container for audit log storage.

2.1 Create a Resource Group (if needed)

  1. In Azure Portal, search for Resource groups
  2. Click + Create
  3. Configure:
    • Subscription: Your Azure subscription
    • Resource group name: rg-netwrix-sqlmi (or your naming convention)
    • Region: Same region as your SQL Managed Instance
  4. Click Review + Create, then Create

2.2 Create a Storage Account

  1. Search for Storage accounts and click + Create
  2. On the Basics tab:
    • Subscription: Your subscription
    • Resource group: Select the created resource group
    • Storage account name: Must be globally unique (e.g., stnetwrixsqlmi001)
    • Region: Same as SQL Managed Instance for optimal performance
    • Performance: Standard (sufficient for audit logs)
    • Redundancy: Locally-redundant storage (LRS) or higher based on requirements
  3. On the Advanced tab (optional):
    • Secure transfer required: Enabled
    • Minimum TLS version: Version 1.2
  4. Click Review + Create, then Create

2.3 Create a Blob Container

  1. Navigate to the deployed storage account
  2. In the left menu, select Containers (under Data storage)
  3. Click + Container
  4. Configure:
    • Name: audit-logs (consistent naming)
    • Public access level: Private (no anonymous access)
  5. Click Create

2.4 Enable System-Assigned Managed Identity for SQL MI

  1. Navigate to your SQL Managed Instance
  2. Go to Identity under Settings
  3. On the System-assigned tab:
    • Set Status to On
    • Click Save
  4. Note the Object ID for the managed identity

2.5 Assign Storage Permissions

Assign the Storage Blob Data Owner role to the SQL Managed Instance:

  1. In the storage account, go to Access Control (IAM)
  2. Click + Add > Add role assignment
  3. On the Role tab:
    • Search and select Storage Blob Data Owner
  4. Click Next to the Members tab
  5. Select Assign access to: Managed Identity
  6. Click + Select members
  7. Choose SQL Server and select your SQL Managed Instance
  8. Click Select, then Review + assign

Step 3: Configure Authentication in Azure SQL Managed Instance

Create a login for the Entra ID application to access audit configuration.

3.1 Connect to SQL Managed Instance

Use SQL Server Management Studio (SSMS) or Azure Data Studio with an account that has:

  • Azure AD admin privileges on the SQL MI
  • sysadmin server role or equivalent permissions

3.2 Create Login from External Provider

Execute the following T-SQL commands:

-- Create login using the exact Display Name from Entra ID
CREATE LOGIN [NetwrixSQLMIIntegration] FROM EXTERNAL PROVIDER;

-- Grant basic connection permission
GRANT CONNECT SQL TO [NetwrixSQLMIIntegration];

-- Grant permissions for audit configuration and monitoring
GRANT ALTER ANY SERVER AUDIT TO [NetwrixSQLMIIntegration];
GRANT VIEW ANY DATABASE TO [NetwrixSQLMIIntegration];
GRANT VIEW SERVER STATE TO [NetwrixSQLMIIntegration];
GRANT VIEW SERVER SECURITY AUDIT TO [NetwrixSQLMIIntegration];

Note: Replace NetwrixSQLMIIntegration with your actual Azure AD application name. The name must match exactly as shown in Entra ID.

Step 4: Configure Server-Level Audit

Set up comprehensive server-level auditing for login events and security changes.

4.1 Create Storage Credential

USE master;
GO

-- Create credential for Azure Blob Storage using Managed Identity
IF NOT EXISTS (SELECT * FROM sys.credentials
               WHERE name = 'https://stnetwrixsqlmi001.blob.core.windows.net/audit-logs')
BEGIN
    CREATE CREDENTIAL [https://stnetwrixsqlmi001.blob.core.windows.net/audit-logs]
    WITH IDENTITY = 'Managed Identity';
    PRINT 'Created Managed Identity credential for audit-logs container';
END
ELSE
BEGIN
    PRINT 'Credential already exists for audit-logs container';
END
GO

4.2 Create Server Audit

USE master;
GO

-- Drop existing audit if it exists (for redeployment scenarios)
IF EXISTS (SELECT * FROM sys.server_audits WHERE name = 'SERVER_AUDIT')
BEGIN
    ALTER SERVER AUDIT [SERVER_AUDIT] WITH (STATE = OFF);
    DROP SERVER AUDIT [SERVER_AUDIT];
    PRINT 'Existing server audit dropped';
END

-- Create the server audit
PRINT 'Creating server audit...';
CREATE SERVER AUDIT [SERVER_AUDIT]
TO URL (
    PATH = 'https://stnetwrixsqlmi001.blob.core.windows.net/audit-logs',
    RETENTION_DAYS = 2  -- Adjust based on your retention requirements
)
WITH (
    QUEUE_DELAY = 1000,         -- 1 second delay for better performance
    ON_FAILURE = CONTINUE,      -- Continue operation if audit fails
    AUDIT_GUID = NEWID()        -- Unique identifier for audit
);
GO

4.3 Create Server Audit Specification

-- Drop existing specification if it exists
IF EXISTS (SELECT * FROM sys.server_audit_specifications WHERE name = 'SERVER_AUDIT_SPEC')
BEGIN
    ALTER SERVER AUDIT SPECIFICATION [SERVER_AUDIT_SPEC] WITH (STATE = OFF);
    DROP SERVER AUDIT SPECIFICATION [SERVER_AUDIT_SPEC];
    PRINT 'Existing server audit specification dropped';
END

-- Create comprehensive server audit specification
CREATE SERVER AUDIT SPECIFICATION [SERVER_AUDIT_SPEC]
FOR SERVER AUDIT [SERVER_AUDIT]
    ADD (FAILED_LOGIN_GROUP),                    -- Failed login attempts
    ADD (SUCCESSFUL_LOGIN_GROUP),                -- Successful logins
    ADD (SERVER_ROLE_MEMBER_CHANGE_GROUP),       -- Server role membership changes
    ADD (SERVER_PRINCIPAL_CHANGE_GROUP),         -- Server principal changes (logins)
    ADD (LOGIN_CHANGE_PASSWORD_GROUP),           -- Password changes
    ADD (SERVER_STATE_CHANGE_GROUP),             -- Server state changes
    ADD (SERVER_OBJECT_CHANGE_GROUP),            -- Server object changes
    ADD (SERVER_PERMISSION_CHANGE_GROUP),        -- Server permission changes
    ADD (AUDIT_CHANGE_GROUP),                    -- Audit configuration changes
    ADD (SERVER_OBJECT_OWNERSHIP_CHANGE_GROUP)   -- Ownership changes
WITH (STATE = OFF);
GO

-- Enable audit specification first, then audit
ALTER SERVER AUDIT SPECIFICATION [SERVER_AUDIT_SPEC] WITH (STATE = ON);
PRINT 'Server audit specification enabled';

ALTER SERVER AUDIT [SERVER_AUDIT] WITH (STATE = ON);
PRINT 'Server audit enabled successfully!';
GO

Step 5: Configure Database-Level Audit

Set up database-specific auditing for comprehensive monitoring.

5.1 Database Audit Configuration Script

-- Variables - modify these for your environment
DECLARE @DatabaseName NVARCHAR(128) = 'YourDatabaseName'; -- Change to your database name
DECLARE @ServerAuditName NVARCHAR(128) = 'SERVER_AUDIT'; -- Must match your server audit name
DECLARE @DatabaseAuditSpecName NVARCHAR(128) = 'DATABASE_AUDIT_SPEC';

-- Validate database exists
IF NOT EXISTS (SELECT * FROM sys.databases WHERE name = @DatabaseName)
BEGIN
    PRINT 'Database ' + @DatabaseName + ' does not exist!';
    RETURN;
END

DECLARE @SQL NVARCHAR(MAX);

-- Switch to target database and create audit specification
SET @SQL = N'
USE [' + @DatabaseName + N'];

-- Drop existing database audit specification if it exists
IF EXISTS (SELECT * FROM sys.database_audit_specifications
           WHERE name = ''' + @DatabaseAuditSpecName + N''')
BEGIN
    PRINT ''Dropping existing database audit specification...'';
    ALTER DATABASE AUDIT SPECIFICATION [' + @DatabaseAuditSpecName + N'] WITH (STATE = OFF);
    DROP DATABASE AUDIT SPECIFICATION [' + @DatabaseAuditSpecName + N'];
END

PRINT ''Creating database audit specification for: ' + @DatabaseName + N''';

CREATE DATABASE AUDIT SPECIFICATION [' + @DatabaseAuditSpecName + N']
FOR SERVER AUDIT [' + @ServerAuditName + N']
    -- User and Role Management (CreateUserStatement, DropUserStatement, AlterUserStatement)
    ADD (DATABASE_PRINCIPAL_CHANGE_GROUP),

    -- Role Operations (CreateRoleStatement, DropRoleStatement, AlterRoleStatement)
    ADD (DATABASE_ROLE_MEMBER_CHANGE_GROUP),

    -- Permission Changes (GrantStatement, RevokeStatement, DenyStatement)
    ADD (DATABASE_PERMISSION_CHANGE_GROUP),

    -- Schema Operations (CreateSchemaStatement, DropSchemaStatement)
    ADD (SCHEMA_OBJECT_CHANGE_GROUP),

    -- Table Operations (CreateTableStatement, DropTableStatement, AlterTableStatement and etc)
    ADD (DATABASE_OBJECT_CHANGE_GROUP),

    -- Ownership Changes (AlterAuthorizationStatement)
    ADD (DATABASE_OBJECT_OWNERSHIP_CHANGE_GROUP),

    -- Backup/Restore Operations (BackupStatement, RestoreStatement)
    ADD (BACKUP_RESTORE_GROUP),

WITH (STATE = OFF);

-- Enable the database audit specification
ALTER DATABASE AUDIT SPECIFICATION [' + @DatabaseAuditSpecName + N'] WITH (STATE = ON);
PRINT ''Database audit specification enabled for: ' + @DatabaseName + N''';
';

EXEC sp_executesql @SQL;

Step 6: Install and Configure Netwrix Add-on

6.1 Launch Add-on Setup Wizard

Run the Netwrix Auditor Add-on Setup Wizard and follow these configuration steps:

6.2 Netwrix Auditor Server Connection

First Screen Configuration:

  • Endpoint URL: URL of your Netwrix Auditor Server
  • Credentials: Valid credentials with sufficient privileges to register and manage data sources

6.3 Application Settings

Microsoft Entra ID Authentication:

  • Tenant ID: Directory (tenant) ID from Step 1
  • Client ID: Application (client) ID from Step 1
  • Client Secret: The secret value you copied in Step 1

6.4 Target SQL Settings

Azure SQL Managed Instance Connection:

  • Azure SQL Server URL:
    your-sql-instance.public.<region>.database.windows.net,1433
  • Database Name: master (for audit collection)
  • Authentication: Azure Active Directory
  • Blob Path: Full path to audit logs container:
    https://stnetwrixsqlmi001.blob.core.windows.net/audit-logs/<managed-instance-name>

6.5 Finalize Setup

  1. Review all configuration parameters
  2. Click Run to complete the setup
  3. Monitor the initial synchronization process

Azure SQL MI - Wizard

Netwrix Auditor - Search
Netwrix Auditor - Search1920×1080 168 KB

Limitations and Considerations

Current Limitations

  • Single Instance Support: This add-on version supports monitoring one Azure SQL Managed Instance per installation
  • Processing Delay: There may be a delay between events occurring and appearing in Netwrix Auditor

Future Enhancements

  • Support for multiple SQL Managed Instances
  • Advanced filtering and categorization options
  • Real-time event processing capabilities
  • Enhanced reporting and analytics features

Support and Feedback

This Azure SQL Managed Instance add-on is a free integration solution for Netwrix Auditor.

We value your feedback! Your experience and suggestions help us improve the add-on. Please share your feedback on:

  • Functionality and features
  • Documentation and setup process
  • Additional requirements or use cases

Additional Resources

Microsoft Documentation

7 Likes
Netwrix Auditor Version 10.8 Released
